AWS Lambda extensions solve the problem of having to include additional code or dependencies within the Lambda function itself. Instead, Lambda extensions are separate processes that can be loaded into the same runtime environment as the Lambda function, allowing for additional functionality and customization without affecting the function's code or performance. This can simplify the development process and improve the overall manageability of Lambda functions. Some examples of use cases for Lambda extensions include:

  • Customizing the runtime environment, like fetching configuration settings or secrets before the function's invocation.

  • Improving observability, capturing diagnostic information before, during and after function invocation.

  • Integrating functions with other monitoring, observability, security, and governance tools.

We can find information about AWS Lambda extensions here. Now, let's see how to build an extension using .NET.

Prerequisites

  • An IAM User with programmatic access.

  • Install AWS CLI.

  • Install the Amazon Lambda Templates (dotnet new -i Amazon.Lambda.Templates).

  • Install the Amazon Lambda Tools (dotnet tool install -g Amazon.Lambda.Tools).

Creating a Lambda Function

Run the following commands to create a Lambda function:

dotnet new lambda.EmptyFunction -n HelloWorldApi -o .
dotnet add src/HelloWorldApi package Amazon.Lambda.APIGatewayEvents
dotnet new sln -n DotnetExtensionSandbox
dotnet sln add --in-root src/HelloWorldApi

Open the solution, go to the HelloWorldApi project, and update the Function.cs file as follows:

using Amazon.Lambda.APIGatewayEvents;
using Amazon.Lambda.Core;

[assembly: LambdaSerializer(typeof(Amazon.Lambda.Serialization.SystemTextJson.DefaultLambdaJsonSerializer))]
namespace HelloWorldApi
{
    public class Function
    {
        public async Task<APIGatewayHttpApiV2ProxyResponse> FunctionHandler(APIGatewayHttpApiV2ProxyRequest input, ILambdaContext context)
        {
            return new APIGatewayHttpApiV2ProxyResponse
            {
                Body = @"{""Message"":""Hello world!""}",
                StatusCode = 200,
                Headers = new Dictionary<string, string> { { "Content-Type", "application/json" } }
            };
        }
    }
}

How does it work?

A Lambda extension can be deployed as a Lambda layer. When the Lambda service starts an execution environment, it extracts the content of the layer into the /opt directory. Lambda then looks for any extensions in the /opt/extensions directory and starts initializing them. Extensions need to be executable as binaries or scripts and can be explained with the following pseudo-code:

extentions_api.register();
while (true) {
    response = extentions_api.next();
    if (response.type == “shutdown”)
    {
        shutdown_code();
        break;
    }
    do_something();
}

During the init phase, each extension needs to register with Lambda to receive events (invoke and shutdown). Lambda uses the full file name of the extension to validate that the extension has completed the bootstrap sequence. Therefore, each Register API call must include the Lambda-Extension-Name header with the full file name of the extension. We will receive the Lambda-Extension-Identifier header that is required for all subsequent requests.

To process events during the invoke phase, we need to define a loop and call the Next API (this is a blocking call) until a shutdown event is received. When a Lambda function is invoked sends an event to each extension that is registered for the event.

When Lambda is about to shut down sends a shutdown event to each registered extension. Extensions can use this time for final cleanup tasks.

Creating a Lambda Extension

Run the following commands to create a Lambda extension:

dotnet new console -n MyExtension -o src/MyExtension
dotnet sln add --in-root src/MyExtension

Go to the MyExtension project and create a Payload.cs file with the following content:

namespace MyExtension
{
    public enum EventType
    {
        INVOKE,
        SHUTDOWN,
    }

    public class Payload
    {
        public EventType EventType { get; set; }
        public string? RequestId { get; set; }
        public string? InvokedFunctionArn { get; set; }
        public decimal DeadlineMs { get; set; }
        public string? ShutdownReason { get; set; }
    }
}

Create an Extension.cs file as follows:

using System.Text;
using System.Text.Json.Serialization;
using System.Text.Json;

namespace MyExtension
{
    public class Extension
    {
        private readonly string _name;

        private readonly Uri _registerUrl;

        private readonly Uri _nextUrl;

        private readonly Uri _subscriptionUrl;

        public Extension(string? name)
        {
            _name = name ?? throw new ArgumentNullException(nameof(name), "Extension name cannot be null");

            var apiUri = new UriBuilder(Environment.GetEnvironmentVariable("AWS_LAMBDA_RUNTIME_API")!).Uri;

            _registerUrl = new Uri(apiUri, $"2020-01-01/extension/register");

            _nextUrl = new Uri(apiUri, $"2020-01-01/extension/event/next");

            _subscriptionUrl = new Uri(apiUri, $"2022-07-01/telemetry");
        }

        private async Task<string> Register(HttpClient httpClient)
        {
            var options = new JsonSerializerOptions();

            options.Converters.Add(new JsonStringEnumConverter());

            using var content = new StringContent(JsonSerializer.Serialize(new { events = new EventType[] { EventType.INVOKE, EventType.SHUTDOWN } }, options), Encoding.UTF8, "application/json");

            content.Headers.Add("Lambda-Extension-Name", _name);

            using (var response = await httpClient.PostAsync(_registerUrl, content))
            {
                if (!response.IsSuccessStatusCode)
                {
                    Console.WriteLine($"[{_name}] Error response received for registration request: {await response.Content.ReadAsStringAsync()}");
                    response.EnsureSuccessStatusCode();
                }

                var id = response.Headers.GetValues("Lambda-Extension-Identifier").FirstOrDefault();

                if (string.IsNullOrEmpty(id))
                {
                    throw new ApplicationException("Extension API register call didn't return a valid identifier.");
                }

                return id;
            }
        }

        public async Task Start()
        {
            using (var httpClient = new HttpClient() { Timeout = Timeout.InfiniteTimeSpan })
            {
                var id = await Register(httpClient);

                Console.WriteLine($"[{_name}] Registered extension with id = {id}");

                httpClient.DefaultRequestHeaders.Add("Lambda-Extension-Identifier", id);

                while (true)
                {
                    var payload = await GetNext(httpClient);

                    if(payload.EventType== EventType.SHUTDOWN)
                    {
                        Console.WriteLine($"[{_name}] Shutting down extension: {payload.ShutdownReason}");
                        break;
                    }

                    Console.WriteLine($"[{_name}] Handling invoke from extension: {payload.RequestId}");
                }
            }
        }

        private async Task<Payload> GetNext(HttpClient httpClient)
        {
            var contentBody = await httpClient.GetStringAsync(_nextUrl);

            var options = new JsonSerializerOptions() { PropertyNameCaseInsensitive = true };

            options.Converters.Add(new JsonStringEnumConverter());

            return JsonSerializer.Deserialize<Payload>(contentBody, options)!;
        }
    }
}

Update the Program.cs file as follows:

using System.Reflection;

namespace MyExtension
{
    class Program
    {
        static async Task Main(string[] args)
        {
            var name = (1 == args.Length)
                ? args[0]
                : Assembly.GetEntryAssembly()?.GetName()?.Name;

            await new Extension(name).Start();
        }
    }
}

Building and Deploying

Create a template.xml file (AWS SAM) with the following content:

AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31
Description: >
  Lambda Extensions

Resources:

  MyExtensionLayer:
    Type: AWS::Serverless::LayerVersion
    Properties:
      ContentUri: ./publish/

  MyFunction:
    Type: AWS::Serverless::Function
    Properties:
      Timeout: 60
      MemorySize: 512
      Runtime: dotnet6
      Layers:
        - !Ref MyExtensionLayer
      Architectures:
        - x86_64
      Handler: HelloWorldApi::HelloWorldApi.Function::FunctionHandler
      CodeUri: ./src/HelloWorldApi/
      Events:
        ListPosts:
          Type: Api
          Properties:
            Path: /
            Method: get

Run the following command for building and packaging the extension:

dotnet publish ./src/MyExtension/MyExtension.csproj --configuration Release --runtime linux-x64 -p:PublishSingleFile=true -p:PublishTrimmed=true -p:DebugSymbols=false -p:DebugType=None --self-contained true --output ./publish/extensions

Run sam build and sam deploy --guided and follow the instructions to deploy the Lambda function and extension. Check the Lambda function logs to see the outputs written by our extension.

The code is available here. Thanks, and happy coding.
